| Selling Units: | Bag/Bags |
|---|
Transportation: Others
| CONTENT | METRIC INFO. |
| ITEM NO. | 10121160/10121161/10121162/10121163 |
| Specification | |
| Max. swing dia. over bed | 650mm |
| Max. swing dia. over slide | 375mm |
| Maximum turning diameter (disc) | 650mm |
| Max.work piece length | 1000/1500/2000/3000mm |
| Maximum turning length | 900/1400/1900/2900mm |
| Spindle nose | C11 |
| spindle bore | 105 Φ/mm |
| Spindle taper | Metric120/1:20 |
| Spindle speed | 10-85,40-350,100-850r/min |
| Spindle shift mode | 3-gear spindle speed, step-less in gear |
| Spindle motor power | 11Kw |
| Chuck type | Manual chuck |
| Chuck size | 320mm |
| X axis rapid traverse | 4 m/min |
| Z axis rapid traverse | 5 m/min |
| X axis servo motor torque | 10 N.m |
| Z axis servo motor torque | 15/22/30 N.m |
| X axis travel | 400mm |
| Z axis travel | 1100/1600/2100/3100mm |
| Guide way type | hard guide |
| Capacity of tool post | 4 |
| Tool shank size | 32X32 mmxmm |
| Tail stock quill dia | 100 Φ/mm |
| Tail stock quill travel | 250mm |
| Tail stock quill taper | MT6# |
| Total rated power | 16/18/20Kw |
| Total rated current | 36/40/42A |
| Net weight | 4000/4400/5000/5800Kg |
| Machine dimension(LxWxH) | 3300/3800/4300/5300x1900x1900mm |
| Features | |
|
| Details | |
