| ITEM NO. | 10128300 | |
| Distance Between Centers | 750mm | 29.53" |
| Swing Over Bed | 300 mm | 11.81" |
| Swing Over Cross Slide | 190 mm | 7.48" |
| Width Of Bed | 182 mm | 7.17" |
| Taper Of Spindle Bore | MT5 | MT5" |
| Spindle Bore | 38 mm | 1.5" |
| Number Of Spindle Speeds | Variable Speed | Variable Speed |
| Range Of Spindle Speeds | 50-2000 rpm | 1.97-78.74 |
| Range Of Cross Feeds | 0.02-0.4 mm/r | 0.0008-0.016"/r |
| Range Of Longitudinal Feeds | 0.02-0.4 mm/r | 0.0008-0.016"/r |
| Range Of Threads | 0.25-4 mm | 0.01-0.16" |
| Top Slide Travel | 65 mm | 2.56" |
| Cross Slide Travel | 170 mm | 6.69" |
| Tailstock Quill Travel | 75 mm | 2.95" |
| Taper Of Tailstock Quill | MT3 | MT3 |
| Motor | 2.2kw | 2.2kw |
| Packing Size | 1680*820*1550mm | 66.14"x32.28"x61.02" |
| Description | Item No. | Size |
| Steady rest | 30008001 | 0-55mm |
| Follow rest | 30008002 | 0-50mm |
| Face plate | 30008003 | 240mm |
| 4-jaw chuck | 22014104 | 160mm |
| Back plate | 30008005 | 160mm |
| Leadscrwe cover | 30008015 | |
| Tool post cover | 30008020 | |
| New style tool post cover with switch-off | 30008021 | |
| Stand | 30008030 | |
| Luxury Stand | 30008035 | |
| Super Stand | 30008038 | Heavy duty & height adjustable wheel with locking system |
| Wedge type tool post set | 22123021 | 251-111 |
| Euro type tool post set | 22121001 | TOOA1 |
| Carbide Turning Tools | 21000033 | 11PCS 12x12mm |
| Chrome Tin Alloy Turning Tool Set | 21000117 | 7 PCS 12x12mm |
| ER32 Collect Fixture | 22050109 | ER32-130/160 |
| 2-Axis DRO Magnetic scales | 23071247 | 750mm |
| 3-Axis DROMagnetic scales | 23071347 | 750mm |
| 2-Axis DRO Magnetic scales LED (D80) | 23073247 | 750mm |
| 3-Axis DRO Magnetic scales LED (D80) | 23073347 | 750mm |
| SINO 2-axis DRO | 23080247 | 750mm |
| SINO 3-axis DRO | 23080347 | 750mm |
